Description
Jetax’s Conical and Cylindrical filter cartridges are engineered for superior air inlet filtration in gas turbines. Available in configurations such as Conical/Cylindrical, Conical/Conical, and Cylindrical/Cylindrical, they are ideal for pulsing systems but can also be installed in static applications.
Featuring a high surface area, low-pressure drop, and flexibility for horizontal or vertical installation, these cartridges are designed for demanding conditions—whether in arctic, coastal, industrial, marine, or desert environments. Manufactured with premium Nanoweb (blended polyester) filter media, they deliver consistent performance in power plants, mobile generation units, and oil & gas platforms.
Applications:
- Power Generation Plants
- Mobile Generation Units
- Oil & Gas Platforms
Environments:
- Arctic
- Coastal
- Industrial
- Marine
- Desert
Specifications:
- Filtering Efficiency: 77%
- Number of Pleats: 323
- Effective Filtration Area: 25.8 m² (277.71 ft²)
- Test Air Flow Rate: 1018 m³/h (599 cfm)
- Height: 660 mm (25.98 in.)
- Outside Diameter: 445 / 324 mm (17.52 / 12.75 in.)
- Inside Diameter: 324 / 213 mm (12.75 / 8.38 in.)
- Pleat Depth: 51 mm (2 in.)
- Liners: Galvanized expanded steel
- Standards: EN1822:2009 – Group E (EPA), Group H (HEPA), Group U (ULPA)
